TURCK 100007129 / CT32R/UC24-48V Time Module

11-pin pluggable multifunction time module with solid state output. 0.15 s to 60 m time range. 24 to 48 VDC/AC operating voltage.

$148.00
Part Numbers
  • CT32R/UC24-48V
  • 100007129
Manufactured
Availability
  • Usually ships in 4-6 weeks
Product Specs

Features

  • Design principle: solid state output
  • Time range: 0.15 s to 60 m
    • 4 partial time ranges: 1.5, 6, 15, 60 /s /m
  • Repetition accuracy: ± 0.2 % or ± 20 ms
  • Reset time: ≤ 150 ms
  • Housing material: Lexan
  • Operating temperature: -40 to 85°C / -40 to 60°C (no ice)
  • Socket type: S3-M / S5-M
  • Supply Voltage: 24-48VUC
  • CE, RoHS compliant

The TURCK CT32R/UC24-48V Time Module offers a multifunction 0.15 s to 60 min range unit with solid state output. Units comply with the latest environmental regulations including RohS.
