TURCK 4656523 / BI5-P18SK-AP6X/S80-S277 Inductive Sensors

Inductive Sensor, With Increased Temperature Range.

$352.00
Part Numbers
  • BI5-P18SK-AP6X/S80-S277
  • 4656523
Manufactured
Availability
  • Usually ships in 5-8 weeks
Product Specs

Features

  • Mounting: Embeddable
  • Principle of Operation: Inductive
  • Operating Distance: 5 mm
  • Sensing Characteristics: Standard
  • Housing Material Modifier: Without
  • Housing Style: Barrel, plastic, full threading
  • Primary Barrel Modifier: Standard
  • Housing Diameter or Height: 18 mm
  • Secondary Barrel Modifier: Right-angle terminal chamber
  • Output Function: Normally open (N.O.)
  • Output: PNP transistor (current sourcing)
  • Voltage Range: 10 to 30 VDC, polarity protected, pulsed short circuit and overload protection
  • Number of LEDS: 1
View other configurations.
Inductive Sensor, With Increased Temperature Range, Rated switching distance 5 mm, Flush, Threaded barrel, M18 x 1, Plastic, PA12‐GF30-V0, Temperatures up to +80 °C, DC 3-wire, 10…30 VDC, NO contact, PNP output, Terminal chamber
