TURCK 4602202 / BI1.5-EG08-RP6X-H1341 Inductive Sensors

Inductive Sensor.

Available in other configurations.

$145.20

Part Numbers

BI1.5-EG08-RP6X-H1341
4602202

Manufactured

By TURCK

Availability

Usually ships in 4-6 weeks

Product Specs

Features

Mounting: Embeddable
Principle of Operation: Inductive
Operating Distance: 1.5 mm
Sensing Characteristics: Standard
Housing Material Modifier: Stainless steel
Housing Style: Barrel, full threading, generally chrome plated brass
Primary Barrel Modifier: Standard
Housing Diameter or Height: 08 mm
Secondary Barrel Modifier: Without/Not applicable
Output Function: normally closed (N.C.)
Output: PNP transistor (current sourcing)
Voltage Range: 10 to 30 VDC, polarity protected, pulsed short circuit and overload protection
Number of LEDS: 1

View other configurations.

Inductive Sensor, Rated switching distance 1.5 mm, Flush, M8 × 1 threaded barrel, Stainless steel, 1.4305 (AISI 303), DC 3-wire, 10…30 VDC, NC contact, PNP output, M12 x 1 male connector
