TURCK 4453050 / BI2-P12SK-AD4X Inductive Sensors

Inductive Sensor.

Available in other configurations.

$149.00

Part Numbers

BI2-P12SK-AD4X
4453050

Manufactured

By TURCK

Availability

Usually ships in 4-6 weeks

Product Specs

Features

Mounting: Embeddable
Principle of Operation: Inductive
Operating Distance: 2 mm
Sensing Characteristics: Standard
Housing Material Modifier: Without
Housing Style: Barrel, plastic, full threading
Primary Barrel Modifier: Standard
Housing Diameter or Height: 12 mm
Secondary Barrel Modifier: Right-angle terminal chamber
Output Function: Normally open (N.O.)
Output: 2-wire DC (transistor output)
Voltage Range: 10 to 65 VDC, polarity protected, pulsed short circuit and overload protection
Number of LEDS: 1

View other configurations.

Inductive Sensor, Rated switching distance 2 mm, Flush, Threaded barrel, M12 x 1, Plastic, PA12‐GF30, DC 2-wire, 10…65 VDC, NO contact, Terminal chamber
