TURCK 4283296 / BI20U-CA40-ADZ30X2-B3131/S1590 W/BS 2.1 Inductive Sensors

Inductive Sensor, With WeldGuard™ Coating.

$324.10
Part Numbers
  • BI20U-CA40-ADZ30X2-B3131/S1590 W/BS 2.1
  • 4283296
Manufactured
Availability
  • Usually ships in 4-6 weeks
Product Specs

Features

  • Mounting: Embeddable
  • Principle of Operation: Inductive
  • Operating Distance: 20 mm
  • Sensing Characteristics: Uprox sensor
  • Housing Style: Stubby model limit switch, short aluminum housing, connector
  • Housing Diameter or Height: 40 mm
  • Secondary Housing Modifier: Without/Not applicable
  • Output Function: Normally open (N.O.)
  • Output: 2-wire AC/DC, (power MOSFET output)
  • Voltage Range: 20 to 250 VAC, 10 to 300 VDC 400 mA, latched short circuit and overload protection
  • Number of LEDS: 2
View other configurations.
Inductive Sensor, With WeldGuard™ Coating, Rated switching distance 20 mm, Flush, Rectangular, height 40 mm, Variable orientation of active face in 5 directions, Sensor housing GD-ALSI 12, Active face PA6-GF30, Factor 1 for all metals, Protection class IP67, Resistant to magnetic fields, AC 2-wire, 20…250 VAC, DC 2-wire, 10…300 VDC, NO contact, 1/2" male connector
