TURCK 4280891 / NI40U-CP40-FDZ30X2-B3131 Inductive Sensors

Inductive Sensor, With Extended Switching Distance.

$343.60
Part Numbers
  • NI40U-CP40-FDZ30X2-B3131
  • 4280891
Manufactured
Availability
  • Usually ships in 10-16 weeks
Product Specs

Features

  • Mounting: Non-embeddable
  • Principle of Operation: Inductive
  • Operating Distance: 40 mm
  • Sensing Characteristics: Uprox sensor
  • Housing Style: Combiprox model limit switch, plastic housing, terminal chamber base with removable sensor
  • Housing Diameter or Height: 40 mm
  • Secondary Housing Modifier: Without/Not applicable
  • Output Function: Connection programmable (N.O. or N.C)
  • Output: 2-wire AC/DC, (power MOSFET output)
  • Voltage Range: 20 to 250 VAC, 10 to 300 VDC 400 mA, latched short circuit and overload protection
  • Number of LEDS: 2
View other configurations.
Inductive Sensor, With Extended Switching Distance, Rated switching distance 40 mm, Non-flush, Rectangular, height 40 mm, Variable orientation of active face in 9 directions, Plastic, PBT-GF30-VO, High-luminance corner LEDs, Optimum view of operating voltage and switching state from any position, Factor 1 for all metals, Increased switching distance, Protection class IP68, Large coverage, Resistant to magnetic fields, Extended temperature range, High switching frequency, AC 2-wire, 20…250 VDC, DC 2-wire, 10…300 VDC, NC/NO programmable, ½" connector
