TURCK 4240291 / NI60-K90SR-FDZ30X2-B1131 Inductive Sensors

Inductive Sensor.

Available in other configurations.

$833.80

Part Numbers

NI60-K90SR-FDZ30X2-B1131
4240291

Manufactured

By TURCK

Availability

Usually ships in 8-12 weeks

Product Specs

Features

Mounting: Non-embeddable
Principle of Operation: Inductive
Operating Distance: 60 mm
Sensing Characteristics: Standard
Housing Material Modifier: Without
Housing Style: Smooth, plastic
Primary Barrel Modifier: Standard
Housing Diameter or Height: 90 mm
Secondary Barrel Modifier: Straight terminal chamber
Output Function: Connection programmable (N.O. or N.C)
Output: 2-wire AC/DC, (power MOSFET output)
Voltage Range: 20 to 250 VAC, 10 to 300 VDC 400 mA, latched short circuit and overload protection
Number of LEDS: 2

View other configurations.

Inductive Sensor, Rated switching distance 60 mm, Non-flush, Rectangular, height 60 mm, Plastic, PBT‐GF30‐V0, AC 2-wire, 20…250 VAC, DC 2-wire, 10…300 VDC, NO contact, 7/8 connector, "
