TURCK 1688813 / BID2-H12F-AP6/S312 Inductive Sensors

Inductive Sensor, For High Pressures.

$425.90
Part Numbers
  • BID2-H12F-AP6/S312
  • 1688813
Manufactured
Availability
  • Usually ships in 4-6 weeks
Product Specs

Features

  • Mounting: Embeddable
  • Principle of Operation: Inductive
  • Operating Distance: 2 mm
  • Sensing Characteristics: High pressure sensor, admissible pressure static/dynamic 500/350 bar
  • Housing Material Modifier: Without
  • Housing Style: Barrel, smooth, chrome plated brass or stainless steel
  • Primary Barrel Modifier: Without/Not applicable
  • Housing Diameter or Height: 12 mm
  • Secondary Barrel Modifier: Stainless steel face
  • Output Function: Normally open (N.O.)
  • Output: PNP transistor (current sourcing)
  • Voltage Range: 10 to 30 VDC, polarity protected, pulsed short circuit and overload protection
  • Number of LEDS: None
View other configurations.
Inductive Sensor, For High Pressures, Rated switching distance 2 mm, Cable length (L) 0.2 m, Flush, Smooth barrel, Ø 12 mm, Metal, chrome-plated brass, admissible static or dynamic pressure 100 bar, DC 3-wire, 10…30 VDC, NO contact, PNP output, Pigtail with male end M12 x 1
