TURCK 1540801 / NI75U-CP80-VP4X2/S10 Inductive Sensors

Inductive Sensor, With Increased Switching Distance.

$491.30
Part Numbers
  • NI75U-CP80-VP4X2/S10
  • 1540801
Manufactured
Availability
  • Usually ships in 3-4 weeks
Product Specs

Features

  • Mounting: Non-embeddable
  • Principle of Operation: Inductive
  • Operating Distance: 75 mm
  • Sensing Characteristics: Uprox sensor
  • Housing Style: Combiprox model limit switch, plastic housing, terminal chamber base with removable sensor
  • Housing Diameter or Height: 80 mm
  • Secondary Housing Modifier: Without/Not applicable
  • Output Function: Complementary outputs: one N.O., one N.C.
  • Output: PNP transistor (current sourcing)
  • Voltage Range: 10 to 65 VDC, polarity protected, pulsed short circuit and overload protection
  • Number of LEDS: 2
View other configurations.
Inductive Sensor, With Increased Switching Distance, Rated switching distance 75 mm, Non-flush, Rectangular, height 41 mm, Plastic, PBT‐GF30‐V0, Thread, 1/2-14 NPT, Factor 1 for all metals, Protection class IP67, Resistant to magnetic fields, Extended temperature range, High switching frequency, DC 4-wire, 10…65 VDC, Changeover contact, PNP output, Terminal chamber
