TURCK 1535795 / BI15-CP40-LIU-H1141 Inductive Sensors

Inductive Sensor, With Analog Output.

$504.80
Part Numbers
  • BI15-CP40-LIU-H1141
  • 1535795
Manufactured
Availability
  • Usually ships in 4-6 weeks
Product Specs

Features

  • Mounting: Embeddable
  • Principle of Operation: Inductive
  • Operating Distance: 1.5 mm
  • Sensing Characteristics: Standard
  • Housing Material Modifier: Without
  • Housing Style: Combiprox model limit switch, plastic housing, terminal chamber base with removable sensor
  • Housing Diameter or Height: 40 mm
  • Secondary Barrel Modifier: Without/Not applicable
  • Output: Linear analog output (current and voltage, 15-30 VDC)
  • Number of LEDS: None
View other configurations.
Inductive Sensor, With Analog Output, Measuring range 4 mm, Max. measuring range 11 mm, Rated switching distance 15 mm, Flush, Rectangular, height 40 mm, Variable orientation of active face in 9 directions, Plastic, PBT‐GF30‐V0, 4‐wire, 15…30 VDC, Analog output, 0…10 V and 0…20 mA, M12 x 1 male connector
