TURCK 1310096 / BI2-Q12-AZ31X-0.2-SB3T Inductive Sensors

Inductive Sensor.

Available in other configurations.

$209.20

Part Numbers

BI2-Q12-AZ31X-0.2-SB3T
1310096

Manufactured

By TURCK

Availability

Usually ships in 8-12 weeks

Product Specs

Features

Mounting: Embeddable
Principle of Operation: Inductive
Operating Distance: 2 mm
Sensing Characteristics: Standard
Housing Style: Rectangular style, metal or plastic
Housing Diameter or Height: 12 mm
Secondary Housing Modifier: Without/Not applicable
Output Function: Normally open (N.O.)
Output: 2-wire AC or 2-wire AC/DC
Voltage Range: 20 to 250 VAC, 10 to 300 VDC, plastic barrel, without short circuit and overload protection
Number of LEDS: 1

View other configurations.

Inductive Sensor, Rated switching distance 2 mm, Cable length (L) 0.2 m, Flush, Rectangular, height 12mm, Active face, lateral, Plastic, PA12‐GF30, AC 2-wire, 20…250 VAC, DC 2-wire, 10…300 VDC, NO contact, Cable with connector
